Fiber Optic Terminal Box
OTB-0216-H
1.Basic information
Material: ABS plastic
IP65 waterproof
Cable port: 2 cable port for max. 12.5mm cable entry; 24 drop cable output ports
Adapter plate: 24 SC simplex adpater ports
Can load 1pc 1X16 splitter cassette or 2pcs 1X8 splitter cassettes
Capacity: 24 fibers splicing
1 splice tray in the bottom
Application: wall mounted or pole mounted
2.Packing information:
6pcs per carton, 58x37x36cm
3.Accessories:
Item | Name | Specification | Qty |
1 | Heat shrinkable protection sleeve | 60mm*2.6mm*1.2mm | 24 pcs |
2 | Large flat head self tapping screws | C type 5*40/metal | 3 pcs |
3 | Plastic expansion tube | Ф8*40mm, plastic, white | 3 pcs |
4 | Nylon tie | 3mm*100mm, white | 8 pcs |
5 | Plastic tube | External diameter Ф4mm thickness 0.6mm, plastic, white | 0.5 meter |
